AG Neovo

AG Neovo PN-55D3 55-Inch 1080p 500 Nits Ultra Narrow Bezel Video Wall Display

AG Neovo PN-55D3 55-Inch 1080p 500 Nits Ultra Narrow Bezel Video Wall Display

SKU:PN-55D3

Regular price £2,039.12 GBP
Regular price Sale price £2,039.12 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

Out of stock

Features

  • Full HD 1920 x 1080 resolution
  • Anti-glare treatment (with a haze of 28%) improves screen visibility under ambient light
  • Ultra-narrow bezel, with a width of 2.3 mm (top/left) and 1.2 mm (bottom/right), creates a seamless 3.5mm LCD video wall
  • UniWall™ enables the creation of video walls (up to 15×15 displays) without third-party equipment
  • Flexible display orientation, with landscape and portrait options

The PN-55D3 55-Inch 1080p 500 nits ultra-narrow bezel displays are designed for commercial and professional large-scale video wall installations. Given its built-in scheduler, OPS slot, UniWall™ feature, the PN-55D3 high-end video wall displays can easily create 15×15 large-scale and eye-catching digital content without third-party devices. The anti-reflective, 500 nits brightness panel makes visually stunning video walls in demanding environments — from large public venues to 24/7 operation control rooms.

IMMERSIVE VISUAL EXPERIENCE

To ensure that viewers are presented with an uninterrupted visual experience, the PN-55D3 features IPS panel technology with 24/7 operation. The display is further enhanced by a minuscule 3.5 mm bezel-to-bezel transition to create immersive video walls.

ANTI-GLARE COATING WITH HIGH VISIBILITY

Anti-glare treatment with the haze of 28%, high contrast, wide viewing angles, and 500 nits brightness produce images with superior clarity and visibility under ambient light.

PATENTED ANTI-BURN-IN™ TECHNOLOGY

To combat the effects of traditional LCD burn-in or ghosting, AG Neovo utilises its patented Anti-Burn-in™ Technology to prevent image burn-in and ensure an extended lifespan for displays.

GAMMA SETTINGS FOR CORRECTING COLOUR TONES

The PN-55D3 video wall displays can provide real-time adjustment on the spot. Additionally, multiple sets of Gamma settings produce smoother and more consistent colour tones.

COLOUR CALIBRATION FOR VIDEO WALL SETUP

Screen colour varies due to temperature changes or after long-term use. Fortunately, AG Neovo offers a colour calibration tool, which detects each area using on-screen sensors and automatically fine-tunes colours and details for large-scale display installations.

15X15 LARGE-SCALE VIDEO WALLS

The UniWall™ feature allows the PN-55D3 to natively support video walls of up to 15×15 displays, which can easily be connected to external sources.

DISPLAYPORT 1.2 MULTISTREAM AND IR/RS232 CONTROL CAPABILITY

The DisplayPort 1.2 Multistream functionality allows users to set up, configure, and maintain a 2×2 4K video wall with ease. Users can also easily control multiple PN-55D3 displays via IR or RS232 connections to external devices.

POWERFUL OPS SLOT-IN OPTION

The embedded OPS slot is ready for standardised OPS module installation. Accordingly, the PN-55D3 video wall displays can be seamlessly upgraded to powerful digital signage that is tailor-made for various user scenarios.

LANDSCAPE/PORTRAIT CAPABILITY

The PN-55D3 video wall displays are signage-friendly and can perfectly fit in landscape or portrait mode for complete screen orientation flexibility and to fulfil the needs of various scenarios.

PID COMMAND & CTRL SOFTWARE

PID Command & Ctrl provides intuitive user interfaces for remote management via laptops and mobile devices and offers the easy creation of video wall displays. The software also features simple colour calibration, temperature checks, IR/key-locking options, and usage monitoring for daily maintenance.

Specification

Panel
  • Panel Type
  • IPS
  • Panel Size
  • 54.6"
  • Max. Resolution
  • FHD 1920 x 1080
  • Pixel Pitch
  • 0.630 mm
  • Brightness
  • 500 cd/m²
  • Contrast Ratio
  • 1200:1
  • Viewing Angle (H/V)
  • 178°/178°
  • Display Colour
  • 1.07B
  • Response Time
  • 5 ms
  • Surface Treatment
  • Anti-Glare Treatment (Haze 28%)
  • 2H Hard Coating
Frequency
  • Frequency (H)
  • 31 kHz-92 kHz
  • Frequency (V)
  • 49 Hz-85 Hz
Signal Input
  • DisplayPort
  • 1.2 x 1
  • HDMI
  • 2.0 x 1
  • DVI
  • 24-Pin DVI-D
  • VGA
  • 15-Pin D-Sub x 1
Signal Output
  • DisplayPort
  • 1.2 x 1
External Control
  • IR In
  • 3.5 mm Phone Jack
  • IR Out
  • 3.5 mm Phone Jack
  • RS232 In
  • 2.5 mm Phone Jack
  • RS232 Out
  • 2.5 mm Phone Jack
  • LAN
  • RJ45 x 1
Other Connectivity
  • USB
  • 2.0 x 1 (Service Port)
  • OPS Slot
  • Yes
Audio
  • Audio In
  • Stereo Audio Jack (3.5 mm)
  • Audio Out
  • S/PDIF
  • Stereo Audio Jack (3.5 mm)
  • Internal Speakers
  • 10 W x 2
Power
  • Power Supply
  • Internal
  • Power Requirements
  • AC 100-240V
  • 50/60 Hz
  • On Mode
  • 79W (On)
  • Standby Mode
  • < 0.5W
  • Off Mode
  • 0W
Operating Conditions
  • Temperature
  • 0°C-40°C (32°F-104°F)
  • Humidity
  • 20%-80% (non-condensing)
Storage Conditions
  • Temperature
  • -20°C-60°C (-4°F-140°F)
  • Humidity
  • 10%-90% (non-condensing)
Mounting
  • VESA FPMPMI
  • Yes (400 x 400 mm)
Security
  • Kensington Security Slot
  • Yes
Dimensions
  • Product w/o Base (W x H x D)
  • 1213.4 x 684.2 x 102.7 mm (47.8" x 26.9" x 4.0")
  • Packaging (W x H x D)
  • 1395.0 x 838.0 x 280.0 mm (54.9" x 33.0" x 11.0")
Weight
  • Product w/o Base
  • 26.6 kg (58.6 lb)
  • Packaging
  • 35.3 kg (77.8 lb)
Accessories
  • Supplied
  • Batteries
  • DVI Cable
  • HDMI Cable
  • IR Sensor
  • Power Cord
  • Quick Start Guide
  • Remote Control
  • RS232 Cable
  • RS232 Daisy Chain Cable
Optional Accessories
  • Floor Mount
  • FMC-02
  • FMS-01
  • FMS-02
  • Video Wall Mount
  • VWM-01
  • VWM-02
  • Wall Mount
  • LMA-01
  • LMA-02
  • Ceiling Mount (Landscape only)
  • CMP-01 + LMK-01
  • Wall Mount (Landscape only)
  • LMK-01
  • LMK-03
  • Floor Mount (Landscape only)
  • FMC-03 + LMK-04
  • FMC-04 + LMK-04
  • FMC-05B
  • FMC-06
  • FWL-01B
  • Desk mount (Landscape only)
  • DTS-01
