Aurora Multimedia CW-1 Wireless HDMI Type Video Transmission System

The CW-1 is a HDMI 1.4b to USB 3.1 4K converter for use with Android, Linux, and Windows. Its small size allows it to discretely hide behind devices.

The CW-1 is powered by the USB port and indicates this with a blue LED. The HDMI input can take up to 4K30 4:4:4 and scale down to 1080p for USB 2.0 usage of 1080p. The CW-1 includes a USB Type-C to USB Type A cable.

Features

• Extremely easy to use compact and light weight stick type TX and RX
• Uncompressed wireless transmission system for HD and SD video
• Utilizing WHDI (MIMO/OFDM) technology
• 5GHz frequency band (license free)
• Multiple video formats and frame rates
• Video input/output: HDMI Type
• Zero frame delay; less than 1ms latency.
• Transmit HD video as far as 328ft (distance may vary)
• Dynamic Frequency Selection (DFS) operates on less congested channels for optimal performance.
• Warrenty: 60 Months

Specifications

• Frequency:
  • US: 5190, 5230, 5270, 5310, 5510, 5550, 5670 MHz
  • EU: 5190, 5230, 5510, 5550, 5670 MHz
• Freq. Selection: Automatic / DFS
• Encryption: WPA2-PSK (AES)
• Transmit Method: WHDI (MIMO)
• Modulation: OFDM (Orthogonal Frequency Diversity Multiplexing)
• Latency: Zero frame (less than 1ms)
• Transmit Range: Up to 50m/164ft (free-line-of-sight)
• Video/Audio:
  • TX:(1)HDMI type plug 1.3
  • RX:(1)HDMI type jack 1.3
• Video Formats:
  • YCbCr 4:2:2 10-bit
  • 1080i: 59.94/50Hz
  • 1080p: 30/29.97/25/24/23.98Hz
  • 720: 59.94/50Hz
  • 525i: 59.94Hz / 525p: 59.94Hz
  • 625i: 50Hz / 625p: 50Hz
  • SXGA, XGA, SVGA, VGA
• Power Requirement: DC5V (TX: Mini USB Type AB / RX: Pin Jack 3.5φx 1.35φ)
• Power Consumption:
  • TX: 3.5W max
  • RX: 5W max
• Dimensions:
  • TX: 3.6(H) x 1.2(W) x 0.6(D) inches approx.
  • RX: 3.8(H) x 2.2(W) x 0.8(D) inches approx.
• Weight:
  • TX: 0.7 oz approx.
  • RX: 2.1 oz approx.
